Mini 3 Port 1080P Video HDMI Switch Switcher Splitter with IR Remote

This is a kind of high performance mini HDMI Switcher. It is compatible well for HD-DVD, Sky-HD, STV, PS3, Xbox 360, etc, which has not only key-press-switching function, but also has IR remote control and intelligent function.

Features:

Support HDMI 1.3b.
Full HD 1080P.
Support 12-bit deep color.
High performance up to 2.5Gbps.
IR extender receiver(included).
IR remote control(included).
No power needed(If the input equipment is standard, otherwise power needed).
Multifunction on switching: intelligent or mechanical.
Support uncompressed audio such as LPCM.
Support compressed audio such as DTS Digital, Dolby Digital.
It is compatible well for HD-DVD, Sky-HD, STV, PS3, Xbox 360, etc.
HDCP pass-through.
Specifications
Input DDC Signal: 5 volts p-p(TTL)
Output Video: HDMI 1.3b
Maximum Single Link Range: 1920 * 1080p
Vertical Frequency Range: 50/60Hz
Video Amplifier Bandwidth: 2.5Gbps/250MHz
Resolutions: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Operating Temperature: 0¿¿¿ to + 70¿¿¿
Operating Humidity: 10% to 85% RH
Storage Temperature: -10¿¿¿ to + 80¿¿¿
Storage Humidity: 5% to 90% RH
Consumption(Max): 5W
Item size: 8 * 5.8 * 1.8cm
Item weight: 88g

Package includes:

1 * HDMI Switcher
1 * Remote Control
1 * IR Extender Receiver
1 * User Manual
