Mini DVR Hidden Camera Quadband GSM SIM Card X009 Quad Band GSM 850/900/1800/1900MHz
Technical Parameters
Model X009
Size 55mm (L) x 45mm (W) x 14mm (H)
Camera Sensor Type : CMOS
Expansion Card micro SD card
Battery Polymer(450mAh)
Software Version X009DZ-FLASH128+32-LBS-01020120825
functional operation
On / off machineHold the switch / machine keys 3-5 seconds, the boot indicator is flashing continuously until lights out after that they can call;
Hold the switch / machine keys 3-5 seconds, the light lit, lights out is off later
Camera returns
Edit the text "111" sent to this product
Recorded as
Edit the text "222" sent to this product
Recording
Edit the text "333" sent to this product
Positioning
For example: the first pre-authorized 15899783246, 13723798485 authorized person for the second
(1) Send "SZHM # 15899783246 #" to the product, set the first authorized.
Successfully set up an authorized person, the person authorized to edit the text "555" sent to the product, location information will be returned to the message sender.This number is not authorized, will return "not authorized, unable to locate" the message to the message sender.
(2) To increase the authorized person, the first authorized re-send "SZHM # 13723798485 #" set the second authorized person, and so on.
(3) Send "SCHM # 13723798485 #" to the phone, will remove an authorized person.At this point if
Send "SCHM # 15899783246 #" to the phone, will remove all authorized persons.
(4) set up after the success of the first authorized person, other phones will not be re-authorization of the machine, such as the authorization to set the second person, only the first authorized mobile phone to send "SZHM # 13723798485 #".
Note: the default last message the product automatically cancel the order a message on the command to cancel all of the above functions are edit the text "444" to the product
(D) Notice
* Battery runs out, the need to connect the charger to 3 minutes to start charging
* The new machine is fully charged before use in order to achieve the best results, use the original machine equipped with a charging cable
* Charger Standard: ± 5.0V 300-500MA, to avoid damage to the host
* Does not light, battery power, charge and then use
* Get through phone, turn on or charge card and then re-test
* Do not automatically answer, re-boot card
* Controller to be applied to their own custom
* Do not attempt to disassemble, damage is not caused by man-made "three guarantees" range
* This product should never be used for illegal purposes, or they will pursue their legal obligations
Package Contents
1 x X009 Mini Camera
1 X USB Cable
1 X Power Charger
1 X User Manual
