MOCET IG7200 SMARTPHONE GATEWAY FOR HOME/SMALL BUSINESS USE

MOCET IG7200
Ver1.0 140520
Smartphone Gateway
A Dream Companion to Smartphone

When you are at home, the Dream Gateway enables you to receive and place calls on your home fixed telephone line via your smart phone; your smart phone becomes your cordless phone, you do not need to buy cordless phones anymore. And it allow 6 (max) users to enjoy the advantages. All calls among the 6 users are intercom calls, without any charge. Call-Hold and Call-Transfer among the 6 users are also provided for free.


Adds incredible value and advantages to your Smartphone
Saving! easily hundreds dollars per overseas travel
Saving! no need to buy cordless phones
Anywhere! you can use your home telephone lines
Extra Applications of Mocet Smartphone Gateway
The Gateway also supports video home monitor to your Smart-Phone, with the help of Mocet WiFi IP-CAM. When you
leave your home, you can simply put the WiFi IP-CAM anywhere you would like to monitor, and you will receive good
quality video on your Smartphone, with full control of the angles of the lens.
Caller ID issues True, no virture, no surprise
The Smart-Phone Gateway provides true caller ID numbers both on incoming and outgoing calls:
For incoming calls to your home line, the Gateway relays the caller’s true numbers to your smartphone, no virture
numbers, no surprise.
For outgoing calls that you place from anywhere via the Gateway, the called party receives your home telephone
numbers, as if the calls are made at your home.
…. and more
The Dream Gateway enables you to call your home country as local calls, thus saves on the tremendous international
roaming bill.
When you are at home, the Dream Gateway enables you to receive and place calls on your home fixed telephone
line via your Smartphone; your Smartphone becomes your cordless phone, you do not need to buy cordless
phones anymore. And it allows 6 (max) users to enjoy the advantages. All calls among the 6 users are intercom
calls, without any charge. Call-Hold and Call-Transfer among the 6 users are also provided for free.
When you are away from home, the Dream Gateway still enables you to receive and place calls on your home
telephone line via your Smartphone, anywhere there is WiFi or cell phone coverage. Therefore, your Smartphone
essentially becomes a coreless phone with unlimited range. All six users can enjoy the same, wherever they are.


MOCET IG7200
Ver1.0 140520
Smartphone Gateway
A Dream Companion to Smartphone

Hardware Specifications:
- 1 FXO Port (PSTN Line)
- 2 Ethernet Ports (1 10/100 to WAN, 1 10/100 to LAN)
- 1 Auto pairing button
- 1 Power switch
- 1 Reset Button
Data Networking
- Static IP/ Dynamic IP/ PPPoE
- DHCP Server/Client
- Dynamic DNS
- NAT & Routing
- QoS
- Remote Diagnostics/ Management
Specifications:
Physical:
- Dimension : 132 x 100 x 34 mm (W/L/D)
- Weight : 210g
- WiFi 802.11n Access Point
Voice
- SIP: Compliant with IETF RFC3261 standards
- SDP: Compliant with IETF RFC2327 standards
System
- Support up to 6 Smartphone Client Power Supply:
Input : 100~240V
Output : 12V DC, 0.5A
Certifications:
FCC / UL / NCC
IP3051 APPs for Android phone / iPhone
Download from Play Store or Apple Store
Call Features
- Call Hold
- Call Transfer
- Distinctive Ringing
- Make or receive call
- Mute
- Speakerphone
- Contact List
- Call Logs
Add a new call
- Line-In-Use Indication
Copyright © MOCET, 2014. All rights reserved. MOCET logo is the property of MOCET Networks Inc., Texas.
All specifications are subject to change without prior notice.
