Molex (501568-0807) Pin Header, Wire-to-Board, 1 mm, 1 Rows, 8 Contacts,

Pin Header, Wire-to-Board, 1 mm, 1 Rows, 8 Contacts, Surface Mount Right Angle,Pico-Clasp 501568Product OverviewThe 501568-0807 is a 8-circuit 1-row 1.00mm pitch Pico-Clasp Wire-to-boardRight Angle Header with tin-plated brass contacts, positive lock and surfacemount termination. This 501568 series PCB header is made of nylon, mates with501330 Pico-Clasp wire-to-board female housing, suitable for signal andwire-to-board applications. Pico-Clasp wire-to-board connector is a smallestpitch wire-to-board connector with positive lock. The new 1.00mm pitchwire-to-board Pico-Clasp connector system from Molex was developed for variousconnections in Flat Panel Displays (FPD). Friction and positive locks areoffered for various application needs. Other features include mating guides,solder tabs and footprint compatibility.Compact and small circuit sizeProvides space savings for mounting other componentsInner positive lock - Prevents wire hooking, latch protection and secure matingretentionLow mating and un-mating forces - Easy connecter insertion and extractionOuter positive lock - Strong mating retention and clear click feelingNatural colour1A Current rating per contact50V AC/DC Voltage rating-40 to 105°C Temperature rangeApplicationsConsumer Electronics, Computers & Computer PeripheralsProduct InformationConnector Systems: Wire-to-BoardPitch Spacing: 1mmNo. of Rows: 1RowsNo. of Contacts: 8ContactsContact Termination Type: Surface Mount Right AngleProduct Range: Pico-Clasp 501568Connector Shroud: ShroudedContact Material: Phosphor BronzeContact Plating: Tin Plated Contacts
