Molex (90130-3210) Pin Header, Right Angle, Wire-to-Board, 2.54 mm

Pin Header, Right Angle, Wire-to-Board, 2.54 mm, 2 Rows, 10 Contacts, ThroughHole Right AngleProduct OverviewThe 90130-3210 is a 10-circuit 2-row C-Grid III right angle header withgold-plated brass contacts and through hole termination. This 90130 series PCBheader is made of polyester, mates with 90142 C-Grid III crimp housing,suitable for signal and wire-to-board applications. The C-Grid III has beendeveloped to meet the latest industry requirements. Headers will accept bothdiscrete wire and ribbon cable connectors. C-Grid III box contact design employsthe same mating concept with all termination techniques. A uniform lockingsystem on all contacts allows full interchangeability inside different housingstyles. C-Grid III is fully compatible with the industry standard DIN41651 aswell as the French norm HE-13/14. Moreover, it is fullyintermateable/interchangeable with Molex's QF-50 product range.Black colourUL94V-0 flammability ratingCurrent rating per contact is 3AVoltage rating is 350VAC/DCTemperature range from -55 to 125°CApplicationsCommercial Vehicle, Consumer ElectronicsProduct InformationConnector Systems: Wire-to-BoardPitch Spacing: 2.54mmNo. of Rows: 2RowsNo. of Contacts: 10ContactsContact Termination Type: Through Hole Right AngleProduct Range: C-Grid III 90130Connector Shroud: ShroudedContact Material: BrassContact Plating: Gold Plated Contacts
