The MSI A520M-A PRO motherboard supports 3rd Gen AMD Ryzen Desktop Processors and AMD Ryzen 4000 G-Series processors, utilizing the AMD A520 chipset. It features dual-channel DDR4 memory support up to 64GB with speeds reaching 4600 MHz in OC mode, along with a PCIe x16 slot for graphics expansion and four SATA III ports for storage.
Product Overview
The MSI A520M-A PRO motherboard is designed to deliver reliable performance and stability, supporting 3rd Gen AMD Ryzen processors and up to 64GB of DDR4 RAM. It features a robust set of connectivity options, including Gigabit LAN via Realtek RTL8111H, multiple USB ports, HDMI, and DVI-D outputs for versatile display configurations. With its micro-ATX form factor and extensive compatibility with popular memory brands, this motherboard offers flexibility and high-quality audio through Realtek codecs for enhanced user experience
Features
Support 3rd Gen AMD Ryzen Desktop Processors and AMD Ryzen 4000 G-Series Desktop Processors
Supports DDR4 Memory, up to 4600(OC) MHz
Turbo M.2: Running at PCI-E Gen3 x4 maximizes performance for NVMe based SSDs
Core Boost: With premium layout and digital power design to support more cores and provide better performance
DDR4 Boost: Advanced technology to deliver pure data signals for the best performance and stability
2oz Thickened Copper PCB: An enhanced PCB design improves heat dissipation and performance reliability
Audio Boost: Reward your ears with studio grade sound quality
Dragon Center: A brand new software which integrates all MSI exclusive tools with user friendly user interface
Specifications
Description: MSI A520M-A PRO AMD Gaming Motherboard
Socket: AMD Socket AM4
CPU (Max Support): Support 3rd Gen AMD Ryzen Desktop Processors and AMD Ryzen 4000 G-Series Desktop Processors
Chipset: AMD® A520 Chipset
DDR4 Memory: Supports DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz by JEDEC Supports DDR4 2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400/ 4600+ MHz by A-XMP OC Mode
Memory Channel: Dual
DIMM Slots: 2
Max Memory (GB): 64
PCI-E x16: 1
PCI-E GEN: Gen3
PCI-E x1: 1
SATAIII: 4
M.2 Slot: 1
TPM (Header): 1
RAID: 0/1/10
LAN: 1x Realtek® RTL8111H Gigabit LAN
USB 3.2 ports (Front): 2(Gen 1, Type A)
USB 3.2 ports (Rear): 4(Gen 1, Type A)
USB 2.0 ports (Front): 4
USB 2.0 ports (Rear): 2(Type A)
Serial Ports(Front): 1
Audio ports (Rear): Realtek® ALC892/ALC897 Codec
DVI-D: 1
HDMI: 1
DirectX: 12
Form Factor: M-ATX
Operating System: Support for Windows® 10 64-bit
