MSI B450M TOMAHAWK MAX AMD AM4 ATX DESKTOP MOTHERBOARD

FEATURES:
Supports 1st, 2nd and 3rd Gen AMD Ryzen™ / Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with Radeon™ Graphics / Athlon™ with Radeon™ Vega Graphics Desktop Processors for Socket AM4
Supports DDR4 Memory, up to 4133(OC) MHz
Extended Heatsink Design: MSI extended PWM heatsink and enhanced circuit design ensures even high-end processors to run in full speed.
Lightning Fast Game experience: 1x TURBO M.2, AMD Turbo USB 3.2 GEN2, Store MI technology
Core Boost: With premium layout and fully digital power design to support more cores and provide better performance.
DDR4 Boost:Advanced technology to deliver pure data signals for the best gaming performance and stability.
MULTI-GPU: With STEEL ARMOR PCI-E slots. Supports 2-Way AMD Crossfire™
Audio Boost: Reward your ears with studio grade sound quality for the most immersive audio experience.
Flash BIOS Button: Simply use a USB key to flash any BIOS within seconds, without installing a CPU, memory or graphics card.
SPECIFICATIONS:
Socket: AM4
CPU (Max Support): RYZEN 9
Chipset: AMD® B450 Chipset
DDR4 Memory: 1866/ 2133/ 2400/ 2667Mhz (by JEDEC) For AMD Ryzen Gen3 (R5/R7/R9) 2667/2800/2933/3000/3066/3200/3466/3600/3733/3866/4000/4133 by A-XMP OC mode
For AMD Other CPU 2667/2800/2933/3000/3066/3200/3466 by A-XMP OC mode
Memory Channel: Dual
DIMM Slots: 4
Max Memory (GB): 128
PCI-E x16: 2
PCI-E Gen: Gen3(PCI_E1), Gen2(PCI_E4)
PCI-E x1: 3
SATAIII: 6
M.2 Slot: 1
RAID: 0/1/10
TPM (header): 1
LAN: 1x Realtek® 8111H Gigabit LAN controller
USB 3.2 ports (Front): 2(Gen1, Type A)
USB 3.2 ports (Rear): 1(Gen2, Type C), 1(Gen2, Type A), 2(Gen1, Type A)
USB 2.0 ports (Front): 4
USB 2.0 ports (Rear): 2
Serial ports(Front): 1
Audio ports (Rear): Realtek® ALC892 Codec
DVI-D: 1
HDMI: 1
DirectX: 12
Form Factor: ATX
CrossFire: Yes
Operating System: Support for Windows® 10 64-bit, Support for Windows® 7 64-bit
* To support Windows® 7 64-bit, you must install an AMD Pinnacle Ridge & Summit Ridge CPU
