The MSI G41M-SP20 motherboard offers a dependable platform for LGA775-based Intel Core 2 processors. Designed with a compact mATX form factor, this board supports DDR3 memory and Intel G41 chipset for solid mainstream computing. With features like USB Safeguard, APS energy-saving tech, and Live Update 5 utility, it's engineered to deliver longevity, efficiency, and ease of use.
Ideal for legacy system builds or refurbishing older desktops, the G41M-SP20 includes SATA II support, onboard audio, integrated LAN, and a PCI Express x16 slot for GPU upgrades. It also boasts MSI Super Charger support for mobile device fast charging directly from USB.
Key Features & Benefits
Intel G41 Chipset Reliable support for LGA775 Core 2 Quad/Duo processors, including 45nm models
DDR3 Memory Support Up to 8GB of DDR3 1333(OC)/1066/800MHz for improved bandwidth
MSI Super Charger Fast USB charging for mobile phones and tablets, even when the PC is off
APS Technology Active Phase Switching dynamically manages power for greater energy efficiency
M-Flash BIOS USB-based BIOS backup and recovery with no additional chip required
USB Safeguard Built-in anti-ESD protection for improved USB port durability
Easy OC Switch Physical overclock switch for fast system performance boosts
Solid Capacitors on PWM Enhanced thermal stability and reliability over electrolytic caps
Ideal Uses
Legacy System Upgrades Revive older Intel Core 2 Duo/Quad desktops with modern stability features
Office Workstations Run Windows XP/Vista/7-era business software with reliable connectivity
Educational Environments Ideal for budget-friendly school lab setups
Custom Projects Great for hobbyists working on retro PC builds or light automation stations
Specifications
Condition: item in original packaging, opened for verification only
CPU Support: Intel Core 2 Quad/Duo, Pentium, Celeron in LGA775 (up to 95W, FSB 1333 MHz)
Chipset: Intel G41 + ICH7
Memory: 2 x DDR3 DIMM slots, up to 8GB, DDR3 800/1066/1333*(OC)
Expansion Slots:
1 x PCIe x16
1 x PCIe x1
1 x PCI
Storage Interface:
4 x SATA II 3Gb/s
1 x IDE (Ultra DMA 66/100)
Audio: Realtek ALC892, 6-channel HD Audio
LAN: Realtek 8105E PCIe 10/100 Fast Ethernet
Internal I/O:
2 x USB 2.0 headers (4 ports)
1 x Floppy, 1 x IDE, 1 x SPDIF-Out
Front panel, Audio, CPU/System fan headers
Back I/O Ports:
1 x PS/2 keyboard, 1 x PS/2 mouse
1 x VGA
4 x USB 2.0
1 x RJ45
3 x Audio Jacks
BIOS: Plug & Play, DMI, M-Flash
Form Factor: mATX 24.4 cm x 20.0 cm
Mounting: 6 mounting holes
Warranty: 3 Month Carry-in Warranty
What's in the Box: Motherboard only
