MSI RS480/ATX AMD 754 MOTHERBOARD/NEW

CPU

• Supports 64-bit AMD® Athlon™ 64 , Sempron™ and Turion™ 64 processor (Socket 754)
• Supports up to 3700+ Athlon 64, or higher CPU



Chipset

• ATI® Radeon XPRESS 200 Chipset
- HyperTransport™ connection to AMD K8 Athlon64 processor
- 8 or 16 bit control/address/data transfer both directions
- 800MHz "Double Data Rate" operation both direction
- Compliant with PCI Express 1.0a specifications (one x16 graphics interface, which can be divided into two smaller links for use by other devices)
- Graphic integrated

• ATI® SB400 Chipset
- Supports SATA controller up to 150MB/s with RAID 0 or RAID 1
- Integrated Hardware Sound Blaster/Direct Sound AC97 audio
- Ultra DMA 66/100/133 master mode PCI EIDE controller
- ACPI & PC2001 compliant enhanced power management
- Supports USB2.0 up to 8 ports



Main Memory

• Supports four memory banks DDR 333/400, using two 184-pin DDR DIMMs.
• Supports a maximum memory size up to 2GB without ECC.
• Supports 2.5v DDR DRAM DIMM.



Slots

• One PCI Express x 16 slot. (supports PCI Express Bus specification v1.0a compliant)
• Three 32-bit v2.2 Master PCI bus slots (support 3.3v/5v PCI bus interface).



On-Board IDE / SATA

• An IDE controller on the ATI® SB400 chipset provides IDE HDD/CDROM with PIO, Bus
  Master and Ultra DMA 66/100/133 operation modes
- Can connect up to 4 IDE devices

• Serial ATA/150 controller integrated by ATI® SB400
- Up ot 150MB/s transfer rate
- Can connect up to 4 serial ATA devices
- Supports RAID 0 or RAID 1
