Description
Solarix Growtech 5.5KVA 48VDC MPPT Solar Inverter- Single Phase Non-Parallel Pure Sine Wave Inverter, Maximum AC Output 5500W , Output Power Factor 1.0, DC Input 48VDV 127A, DC Output 54VDC, Maximum AC Charge Current 60A , Maximum Charge Current (PV+AC) 100A, Minimum Solar PV Voltage 120VDC, Maximum Solar PV DC Voltage 500VDC, Max PV Array Power 5500W, Colour Beige, Retail Box, 12 Months Limited Warranty
Product Overview
The latest Solarix Growtech 5.5KVA 48VDC 127A Pure Sine Wave Inverter is designed to provide a reliable backup power for medium to large household as well a business office environment installations. Equipped with a MPPT Solar Charge Controller to maximize and regulate DC power from the solar array for charging the battery bank. The Pure Sine Wave 5500w rated output enables easy start-ups for motor-type loads such as refrigerators, as well as electronic loads like TVs. Computers. power tool and battery chargers.
Please note that is a Single Phase Non Parallel Inverter System / Wi-Fi Dongle Is Not Included
Specification
Description Solarix Growtech 5500VA 48VDC Pure Sine Wave Solar Inverter
Product Type Single Phase Non Parallel Inverter System
Output Power factor 1.0
DC Input 48VDC 127A
DC Output 54VDC
AC Input Voltage 220-230VAC 40A
AC Output Power 5.5KVA /5000W
Surge Power Voltage 11000VA
Maximum Input Current 60A
Maximum Charge Current (PV+AC) 100A
Nominal Operating Frequency:50/60HZ 23.9A
Battery Voltage: 48VDC
Battery Floating Voltage 54VDC
Battery Overcharge Protection 63VDC
Charging Method CC /CV
Maximum Peak Efficiency Battery to Inverter 93%
Maximum Peak Efficiency Solar PV to Inverter 97%
Solar PV Charger Type MPPT
Maximum Solar PV Array Power 5500W
Maximum Solar PV Input Current 18A
Maximum Solar PV Charge Current 100A
Minimum Solar PV DC Voltage Range 120VDC-450VDC
Maximum Solar PV DC High Voltage 500VDC
Maximum 100A MPPT Solar Charge Controller
Communication Interface RS232
Dimensions DxWxH 438x295x105
Weight 9.0kg
