RS965T - The Southwire True RMS Multimeter features True RMS measurements for more accurate AC readings and a Low Z setting for eliminating errors caused by ghost voltages. Functions include AC/DC voltage and current, resistance, continuity, capacitance, frequency, duty cycle, temperature, and diode test. The True RMS Multimeter also offers the added convenience of a built-in LED flashlight. This meter is fully tested and calibrated and, with proper use, will provide many years of reliable service.
General Specification
Insulation Class 2, double insulated
Enclosure Double Molded, IP67 waterproof and dustproof
Diode Test Test current 1.5mA typical, open circuit voltage 3V typical
Continuity Test Audible signal if the resistance is approx. 50 ±5 or less
Low Battery Indication " " is displayed
Battery life 150 hours(light off)
Display 6000 count LCD display
Over Range Indication OL is displayed
Polarity Minus symbol - is displayed for negative polarity
Measurement Rate./ 3 readings per second, nominal
Auto Power Off After approx. 15 minutes of inactivity
Input Impedance 10M AC/DC Voltage
Low Z Approx. 3k nput impedance
AC Response True RMS
AC Bandwidth 2kHz
Batteries Four AAA 1.5V alkline batteries 800mA 1000V (6.3 x 32mm) fast blow
Fuses 10A 1000V(10 x 38mm) fast blow
Operating Environment 32°F to 104°F(0°C to 40°C) at <70% relative humidity
Storage Environment 14°F to 140°F(-10°C to 60°C) at <80% relative humidity 2000 Input Limits 3.
Operating Altitude meters maximum
Dimensions/Weight 170 x 75 x 48mm/ 386g
Safety Complies with UL 61010-1 v.3 for measurement Category lV 600V and Category lll 1000V, Pollution Degree 2
