Multi-Port USB Type C Smartphone Super Fast Charging 30 Watt or 20 Watt PD QC 3.0 Charger

Multi-Port USB Type C Smartphone Super Fast Charging 30 Watt or 20 Watt PD QC 3.0 Charger

Charge or power all of your digital devices such as Samsung, Raspberry Pi 4, Huawei, Nokia, Lenovo, LG and many more smartphones and tablets. This charger is a USB-C with PD protocol + USB QC3.0 quick mobile charger 220v Wall Socket for charging via USB to Smartphones / Tablets etc.

30 Watt Chargers Specifications :

• Total Power : 30 Watt (max)
• Super Charging : ± 1 hour 20 minutes for full charging on USB Type C PD Port, Super Charging must be supported on phone such as Huawei, Samsung and other USB Type C Phones. Note that only ONE port can do fast charging / super charging at a time and the charger may disable the other port/s in some cases to protect max power draw circuits. If 2 normal charges occur it can be done from both ports. In such a case when a specific port is disabled due to max charge rate via one port the charger needs to be unplugged and re-plugged to be reset if both ports needs to do standard charging.
• Fast Charging : Less than 2 hours charging time on USB 3.0 Port
• Supports Dual fast charge mode
• Input : AC 100-240 V 50/ 60Hz
• USB Port QC3.0 Output : 5V 3A / 9V 3A / 12V 2.5A / 15V 2A / 20V 1.5A
• Type C Output : 5V 3A / 9V 3A / 12V 2.5V / 15V 2A /20V 1.5A
• Output protections: Short-circuit\Over-current
• Fast Charging Profile: QC3.0 / PD3.0

20 Watt Chargers Specifications :

• Total Power : 20 Watt (max)
• Supports fast charging mode : Most phones less than 2 hours charging depending on battery mAh size. Note that only ONE port can do fast charging at a time and the charger may disable the other port in some cases to protect max power draw circuits. If 2 normal charges occur it can be done from both ports. In such a case when a specific port is disabled due to max charge rate via one port the charger needs to be unplugged and re-plugged to be reset if both ports needs to do standard charging
• Input : AC 100-240 V 50/ 60Hz
• USB Port QC3.0 Output : 5V 3A / 9V 2A / 12V 1.5A
• Type C Output : 5V 3A / 9V 2.22A / 12V 1.67A
• Output protections: Short-circuit\Over-current
• Fast Charging Profile: QC3.0 / PD3.0
