Multicomp Pro (MC001834) Panel Mount Barrier Terminal Block, 2 Row, 10 Ways

Panel Mount Barrier Terminal Block, 2 Row, 10 Ways, 22 AWG, 10 AWG, 12 mm, 41 AProduct OverviewThe MC001834 from Multicomp Pro is a white colour H type dual row terminal blockwith 20 positions. It has minimum insulation withstands voltage of 2000VAC andinsulation resistance of greater than 2000Mohm at 500VDC.Current rating is 41A and voltage rating is 450VPitch spacing is 12mmWire size range from 10AWG to 22AWG5.5mm to 6.5mm stripped length7Lb-inch (0.8Nm) screw torqueOperating temperature range from -40°C to +85°CNatural colour PA66 (UL94-V2) insulating body, tin plated brass wire protectorSteel screw with zinc plating and brass cage clamp with nickel platingEasily cut to sizeApplicationsIndustrialProduct InformationNo. of Rows: 2 RowNo. of Positions: 10WaysWire Size AWG Min: 22AWGWire Size AWG Max: 10AWGPitch Spacing: 12mmRated Current: 41ARated Voltage: 450VProduct Range: MC001
