Multicomp Pro (MC001895) RF/Coaxial Cable Assembly, 90° U.FL Plug to SMA

RF / Coaxial Cable Assembly, 90° U.FL Plug to SMA RP Bulkhead Jack, 1.37mm, 50ohm, 3.9 ", 100 mmProduct InformationConnector to Connector: 90° MCX Plug to SMA Bulkhead JackConnector Type A: SMA Bulkhead JackConnector Type B: MCX Right Angle PlugCoaxial Cable Type: 1.37mmImpedance: 50ohmCable Length - Imperial: 3.9"Cable Length - Metric: 100mmJacket Colour: BlackProduct Range: Miniature Coaxial Cable Assemblies SeriesProduct OverviewThe MC001895 is a 100mm RF Coaxial Cable Assembly, with a Right Angled MCX plugfor electronics and a SMA Panel connector for an antenna. It features a 1.37mmlow-loss cable. Ideal for outdoor RF communications applications. Utilizing1.37mm low-loss cable. Ideal for outdoor RF communications applications1.37mm low-loss micro coaxial cableImpedance: 50 RFrequency range: DC to 6 GHzWorking voltage: 170Vrms max.Dielectric withstanding voltage: 200Vrms max.Insulator resistance: 1000MR min.VSWR: 1.65: 1 max.Insertion loss: -1.1dB max.Sheath colour blackTemperature range-20-+70 degCApplicationsRF Communications
