DescriptionThe product is a PCB mounted solid state relay. Load current is 5A, includingzero cross switching control. Control voltage is4-32V DC. Opto-isolation is 4000VACrms. With a high inrush current capability.The load voltage is 380 Volts.Technical SpecificationInput CircuitControl Voltage Range : 4V DC to 32V DCMin. Turn-On Voltage : 4V DCMin. Turn-Off Voltage : 1V DCMax. Input Current : 25mAOutput CircuitLoad Voltage Range : 24 ~ 440V ACTransient Over Voltage : 800VpkLoad Current Range : 0.1 ~ 5AMax. Turn-On TimeZero Crossing : 10msMax. Turn-off Time : 10msMax. Surge Current (@10 ms) (5A) : 250AMax. Off-State Leakage Current [@ Rated Voltage] : 1.5mAMax. On-State Voltage Drop [@ Rated Current] : 1.5VrmsMin. Off-State dv/dt[@Maximum Rated Voltage] : 500V/?sGeneral InformationDielectric Strength Input/Output (50/60Hz) : ^4000VrmsAmbient Operating Temperature Range : -30°C to +80°CAmbient Storage Temperature Range : -30°C to +100°CWeight (Typical) : 20gApplicationsSuitable for important industrial applications such as lighting control, motorcontrol, medical device, elevator.Features- Plastic case- Zero crossing switching- Ratings from 5A @ 24-530V AC- Control voltage: 4-32VDC- Opto-isolation: 4000V ACrms
