Multifunctional Relay Timer Module (Blue)..!

Multifunctional Relay Timer Module (Blue)..!

Product Information


Features

Normally open or Normally Closed trigger delay 12V relay module, triggered by an external signal
Input Power: DC12V
Output: 1 Channel relay output capacity =10A
Load: AC 250V 10A or DC 30V 10A Max
Environmental requirement: -20~80'C
With Power Off Memory Function
Output Connect Style: Normally open or Normally close
Size: 65x35mm
Delay Time: 0-999 sec

Guide:

1. Calibration time: press set button, it will display F1, and press set button again to calibrate the real time.
    You will use the"+ -" the adjust the time, press the set button to finish.
2. Set begin time: press set button, then press + or - to let it display F2, and press set button again to set the
    begin time, after set the time, press the button to finish.
3. Set end time: press set button, the press + or - to let it display F3, and press set button again to set end time,
    after set the time, press the button to finish.

Classification

PRODUCT TYPE: Modules

Power & Batteries

INPUT TYPE: DC 12V

Package

PACKAGE TYPE: Anti-static
PACKAGE CONTENTS: 1x Multifunctional Timer Relay Module

Dimensions

DEPTH: 10 mm
HEIGHT: 70 mm
WIDTH: 40.1 mm
PRODUCT WEIGHT: 30g
