MUST 5KW 5000VA PV1800 PV18 Parallel Expansion Card

The MUST 5kW PV1800 Parallel Card is an accessory for the MUST PV1800 series of inverters. It is used to parallel multiple PV1800 inverters together, which allows for increased power output and redundancy in case of a failure of one of the inverters.

With the PV1800 Parallel Card, up to 6 PV1800 inverters can be connected in parallel, providing a maximum power output of 30kW. The Parallel Card is easy to install and can be connected to the inverters via a communication cable.

The PV1800 series of inverters is designed for use in solar power systems, and they convert the DC power generated by solar panels into AC power that can be used to power household appliances or fed into the grid. The PV1800 inverters have a built-in MPPT (Maximum Power Point Tracking) function, which allows them to optimize the power output of the solar panels.

In summary, the MUST 5kW PV1800 Parallel Card is an accessory for the MUST PV1800 series of inverters that allows multiple inverters to be connected in parallel for increased power output and redundancy.

Features

- Allows up to 6 PV1800 inverters to be connected in parallel
- Increases power output and provides redundancy
- Easy to install
- Connects to inverters via a communication cable

Specifications

- Maximum output power: 30kW (when 6 PV1800 inverters are connected in parallel)
- Compatibility: MUST PV1800 series inverters
- Communication method: RS485
- Communication distance: 1000m (max)
- Operating temperature: -20 ~ +60
- Storage temperature: -25 ~ +85
- Dimensions: 110mm x 90mm x 29mm (L x W x H)
- Weight: 0.2kg
