• 2 x 40 Watts continuous into 8ohms
• 90 Watts dynamic power into 8ohms
• 160 Watts dynamic power into 2ohms
• Impedance Sensing Circuitry (ISC)
• Full system remote control
• Headphones socket
• Relay input switching
• Toroid power transformer
• 7 Line inputs, including two tape in/outs
• All discrete circuitry
• Short signal path from input to output
• All sockets gold plated
• Tone controls defeat switch
• Pre-out / Main-in
• Soft Clipping
• NAD Link
FEATURES
The C320 has 7 line inputs (including 2 tape in/outputs with dubbing facility) and the pre-amplifier
section can be separated from the power amplifier for easy upgrades (bi-amping, for instance) or adding
ancillary equipment without making the C320 redundant.
SPECIFICATION
PRE-AMP SECTION
Line level inputs
Input impedance (R and C) 20kΩ / 500pF
Input sensitivity (ref. 1W) 165mV
Frequency response 20Hz - 20kHz / ±0.3dB
Line level outputs
Output impedance Pre-out 220Ω
Tape Source Z + 2kΩ
Video 220Ω
Tone controls
Treble ±5dB at 10kHz
Bass ±7dB at 100Hz
POWER AMP SECTION
Continuous output power into 8Ω * 40W (16dBW)
Rated distortion (THD 20Hz - 20kHz) 0.03%
Clipping power (maximum continuous power per channel) 55W
IHF Dynamic headroom at 8Ω +3.5dB
IHF dynamic power (maximum short term power per channel) 8Ω 90W (19.5dBW)
4Ω 125W (21dBW)
2Ω 160W (22dBW)
Damping factor (ref. 8Ω, 50Hz) >60
Signal/noise ratio ref. 1W 90dB
ref. rated power 104dB
Remote Yes
NAD Link Yes
PHYSICAL SPECIFICATIONS
Dimensions (W x H x D) 435 x 100 x 290mm
Net weight 6.5kg
Shipping weight 7.7kg
