NanoBridgeM 5GHz 25dBi

It is extremely small/compact and it's mechanical design provides complete weatherproof performance. Activity and signal strength LED's are provided for installers and it's enhanced RF and Ethernet ESD/Surge protection enables prolonged operation in the harshest environments.

According to Ubiquiti Networks it is a breakthrough in Wireless Performance, with AirMax and AirControl Support. It offers 150+Mbps real outdoor throughput. As with other "M" products, the NanoBridge utilizes Ubiquiti's revolutionary AirMax™ TDMA protocol enabling scalable, carrier-class PtMP network performance. Additionally, the AirControl™ application allows operators to centrally manage several devices.

- Specifications -
- Frequency Range: 5470MHz-5825MHz
- Gain: 25dBi
- Processor Specs: Atheros MIPS 24KC, 400MHz
- Memory Information: 32MB SDRAM, 8MB Flash
- Networking Interface: 1 X 10/100 BASE-TX (Cat. 5, RJ-45) Ethernet Interface
- RoHS Compliance: YES
- Enclosure Characteristics: Outdoor UV Rated Plastic
- Max Power Consumption: 5.5 Watts
- Power Supply: 24V Carrier POE Adapter Included (POE-24)
- Power Method: Passive Power over Ethernet (pairs 4,5+; 7,8 return)
- Operating Temperature: -30C to 75C
- Mounting Kit: Pole Mounting Kit included
- Operating Humidity: 5 to 95% Condensing

- Dimensions: 420mm diameter
- Weight: 135g (feed), 680g(bracket),750g(dish)
