Technical Specification
Mechanical Specifications
Case Material: ABS
Cell Type -Chemistry: Prismatic LiFePO4
Terminal Type: M8
IP Grade: IP65
BMS Characteristics
Recommended Charge Current: 50A
Maximum Charge Current: 100A
Maximum Continuous Discharge Current: 100A
Recommended Charge Voltage: 13.6~13.8V
Max Charge Voltage: 14.4V
Overcharge Protection Voltage: 14.8~15.0V
Charge Mode: CC/CV
Discharge Cut-off Voltage (BMS): 8.8V
Basic Performance
Nominal Voltage: 12.8V
Nominal Capacity: 100Ah
Standard Discharge Time: 100A -60min
Energy: 1.28K Wh
IR: <= 15mQ
Self Discharge: <=2%/Month
Cells: Square 100Ah
Cycle Life: 2500 times
Size: 306x169x215
Weight: 10.1
Charge Performance
Rated Charge Current: 50A
Maximum Charge Current: 100A
Rated Charge Voltage: 13.6~13.8V
Charge Cut-off Voltage: > 14.8V(0.5~1.5S)
Reconnect Voltage: <14.4 V
Balancing Voltage: <14V
System Series: <=4
Discharge Performance
Rated Discharge Current: 100A
Pulse Current(<=5S): 600A
Rated Discharge Cut-off Voltage: 11.2V
Minimum Discharge Cut-off Voltage: >10V
Reconnect Voltage: >10.4V
Short Circuit Protection: 200~800 s
Short Circuit Current: Approx. 1200A
Temperature Performance
Discharge Temperature: -20~60âƒ
Charge Temperature: 0~45âƒ
Storage Temperature: -5~35âƒ
High Temperature Cut-off: 70âƒ
Reconnect Temperature: 50âƒ
