Name: NE555 Pulse Signal Generator
SKU: 3DP-00192
Price: 46.00 ZAR
Availability: InStock

NE555 Pulse Signal Generator

5 available / new

Only 5 left – grab it before it’s gone!

R46.00

Shipping

R65.00 Standard shipping applies to orders under R100.00, in most areas in South Africa. R35.00 Standard shipping applies to orders over R100.00. Some areas may attract a surcharge surcharge. This will be calculated at checkout if applicable.
Check my rate

The seller allows collection for this item. Buyers will receive the collection address and time once the order is ready.

The seller has indicated that they will usually have this item ready to ship within 1 business day. Shipping time depends on your delivery address. The most accurate delivery time will be calculated at checkout, but in general, the following shipping times apply:

Standard Delivery

Main centres:	1-3 business days
Regional areas:	3-4 business days
Remote areas:	3-5 business days

Seller

Netram Technologies665

98.55 % Positive ratings

Get it now, pay later

Condition

New

Location

South Africa

Product code

3DP-00192

Bob Shop ID

644207231

Purpose:

Generate a square wave signal for experimental development use.
Generate a square wave drive signal for driving steppers
Generate adjustable pulse for MCU.
Generate adjustable pulse for control-related circuit.

Features:

Size: 3.1CM * 2.2CM
the main chip: NE555;
Input voltage: 5V-15VDC. When 5V supply, the output current can be at around 15MA; when the 12V supply, the output current can be about 35MA;
the input current: 100MA
the output amplitude:. 4.2V V-PP to 11.4V V-PP (different depending on the input voltage, the output amplitude will be different)
the maximum output current: 15MA (5V power supply, V-PP greater than 50%), 35MA (12V power supply, V-PP greater than 50%)

Advantages:

Output with LED indication, there is no output straightforward (LOW LED quantity, high LED off, LED blink rate is relatively low);
The output frequency range of grades available, the output frequency more continuously adjustable;
- LF file: 1Hz ~ 50Hz
- IF file: 50Hz ~ 1kHz
- High frequency file: 1KHz ~ 10kHz
- High-frequency file: 10kHz ~ 200kHz
You can fine-tune the output duty cycle, duty cycle and frequency are not adjustable, adjust the duty cycle will change the frequency
The output frequency is adjustable: Cycle T = 0.7 (RA +2 RB) C
- RA, RB is 0-10K adjustable;
- At low frequencies file C = 0.001UF;
- Medium frequency when C = 0.1UF;
- High frequency file C = 1UF;
- When high-frequency gear C = 100UF, so the frequency of the waveform buyers can own calculations
