KEY FEATURES
16 ports for Fast Ethernet speed & capacity at a modest price
Each port delivers 200 Mbps of network speed in full-duplex
full-duplex
Full Duplex The term full duplex describes simultaneous data transmission and reception over one channel.
A full duplex device is capable of bi-directional network data transmissions at the same time. Half duplex devices can only transmit in...
...More Info mode
Each port senses the right network speed & duplex mode (half or full)
Easy to set up: Operates as soon as it is turned on, no configuration required
Interoperable with existing 10 & 100 Mbps Ethernet network devices
Rack mountable in a 19-inch rack
NETGEAR presents a great way to increase your network's capability without breaking your budget: the 16-port JFS516. This 10/100 Mbps Fast Ethernet switch provides expanded connectivity for small office networks so users no longer have to compete with each other for bandwidth.
All of the essential features - automatic speed and full/half duplex sensing, 200 Mbps throughput per port, Auto Uplink - are included, but at an economical price that a value-conscious business owner can't ignore.
Performance
Standards
IEEE 802.3, IEEE 802.3u
Protocols
Standard Network Protocols
Ports
16x 10/100 Auto-Negotiation RJ-45 Ports
Speed
Half-Duplex: 10/100 Mbps
Full-Duplex: 20/200 Mbps
MAC Address Table Size
4000
Switching Method
Store-and-Forward
VLANs
None
Management
None
General
Form Factor
Rackmount
System Requirements
Ethernet Network
Environmental Requirements
Operating
Temperature: 32-104° F (0-40° C)
Humidity: 0-80%, non-condensing
Power Requirements
AC: 100-240 VAC, 50/60 Hz
Consumption: 15 watts
Dimensions
13 x 1.7 x 8" (33 x 4.3 x 20.2 cm)
Weight
4.4 lb (2 kg)
