Opcom/Op Com OBD2 Diagnostic Interface for OPEL
Latest version PC based diagnostic program
Version 1.99 firmware
R649 each
Available for Collection or Countrywide Postage.
Package includes: OP-COM Interface USB Cable Software and Drivers CD Description:
OPCOM 2010 OPEL covers almost all Opel cars, even new cars with CAN-BUS based diagnostic, such as Vectra-C, Astra-H, Zafira-B.
The program lets you to read out and clear fault codes, shows you live data, lets you to perform output test. The program supports many control units, like Engine, Automatic Transmission, ABS, Airbag, Engine Cooling module, Instrument Cluster, Electronic Climate Control, and Body Control Unit, just to name a few examples.
Since Opel is used many pin in the OBD connector, the diagnostic interface works as a multiplexer, and selects the appropriate pin for communication.PIN3,PIN7,PIN8=Serial Link (ISO9141, KW81, KW82, KWP2000)
Specification:
Full fault code text description and Full status information (Present, Not present, Intermittent) You can print out, save, or copy the fault codes to any other application. From the fault codes window, you can go directly to the measuring blocks window. The program shows you measuring block information on many control modules; you can choose anything from the list on your own.
2. You can also run output tests on many controllers PIN6-PIN14 PIN3-PIN11 PIN1 HSCAN-Dual-wire, High Speed CAN-BUS,500 kbps MSCAN-Dual-wire, Medium Speed CAN-BUS,95 kbps SWCAN-Single-wire, Low Speed CAN-BUS,33.3 kbps
3. You can learn keys to immobiliser,and remote keys to the central door locking.
4. You can also reset,and program the following immobilizer relate items:ECM,BCM, and IPC. 5. You will need the vehicle security code, which can be found on the CAR-PASS.
6. You can also reset, and program the Service interval reminder on Astra-G, Zafira, Corsa-C, Meriva
7. You can code SAB6, and SAB8 airbags with the software.
8. The diagnostic interface is USB port based, so there will be NO COMPATIBILITY ISSUES,with serial to USB converters.
9. The speed of the communication over the USB-BUS is enough to handle the awesome speed of the High-Speed CAN-BUS systems, which is currently 500kbps.This is the main reason, why only the USB port based interface is available for CAN-BUS.
10. Compared to the TECH2, which is the dealers tool (with a 32 MB Card+CANdi interface); the price of OP-COM is quite affordable.
