Newland NQuire 1000 Manta III Smart, Interactive Micro Kiosk for Retail & More
The Newland NQuire 1000 Manta III is a powerful and versatile micro kiosk designed to enhance customer interaction and streamline operations in retail, hospitality, healthcare, and industrial environments. Featuring a 10.1" capacitive touchscreen, Android 13 OS, and megapixel 2D barcode scanning, it supports a wide range of applicationsfrom self-check-in and price checking to inventory management and secure access.
Built for flexibility, the Manta III offers landscape or portrait mounting, Power over Ethernet (PoE), and multiple connectivity options including WiFi, Bluetooth 5.2, 4G, and Ethernet. Optional modules for NFC and MSR expand its capabilities for contactless payments, ID verification, and legacy systems.
With Newland's Ndevor MDM software, you can manage devices, apps, and settings remotelymaking deployment and maintenance effortless across multiple locations.
Key Features:
- Android 13 GMS with 2.0GHz octa-core processor
- 10.1" capacitive touchscreen (1280×800) for rich user interaction
- Megapixel 2D barcode scanner with laser aimer
- Built-in 4G, WiFi dual-band, Bluetooth 5.2, GPS & PoE
- Optional NFC and MSR modules for expanded functionality
- VESA75 mounting for landscape or portrait orientation
- IP54-rated front panel with 1.2m drop resistance
- Ndevor MDM software for centralized device management
- Includes wall mount bracket and multiplug adapter
- 2-year warranty (extendable to 5 years)
Ideal for: Retail price checkers, hotel self-check-in, pharmacy kiosks, warehouse terminals, and customer-facing service points.
Technical Specifications
Category | Specification |
|---|
Operating System | Android 13 GMS |
Processor | 2.0GHz Octa-Core 64-bit |
Memory | 4GB RAM / 64GB Flash |
Display | 10.1" capacitive touchscreen (1280×800) |
Barcode Scanner | Megapixel 2D CMOS imager with laser aimer |
Camera | Front: 8MP |
Interfaces | USB Type-C, USB Type-A, 2×GPIO, RJ45 Ethernet, MicroSD (up to 128GB) |
Wireless | WiFi 802.11 a/b/g/n/ac (2.4GHz & 5GHz), Bluetooth 5.2, 4G LTE, GPS |
SIM/TF Slots | Nano+Nano or Nano+TF |
NFC (Optional) | 13.56MHz RFID: ISO14443A/B, MIFARE, FeliCa, ISO15693 |
MSR (Optional) | Magnetic Stripe Reader (Track 1, 2, 3) |
Mounting Options | VESA75 (landscape or portrait), wall mount bracket included |
Sensors | Gravity sensor, infrared sensor |
Notifications | Speaker, multicolor LEDs |
Power Supply | 12V/3A adapter or PoE (IEEE 802.3 af/at) |
Environmental | Operating Temp: -10°C to 50°C; Storage Temp: -20°C to 60°C; Humidity: 590% |
ESD Protection | ±12kV (air), ±6kV (direct) |
IP Rating | IP54 (front only) |
Software | Ndevor MDM, Newland Android API support |
Dimensions | 251.7 × 173.5 × 32 mm |
Weight | Varies by configuration |
Warranty | 2-Year Manufacturer's Carry-In Warranty |
