Gigabyte Nvidia GeForce GTX 780 GHz Edition Graphic Card - 3GB GDDR5
Features
- WINDFORCE 3x 450W Cooling system
- Powered by NVIDIA GeForce GTX 780 GPU
- Integrated with industry's best 3GB GDDR5 memory 384-bit memory interface
- Features Dual-link DVI-I/ DVI-D / HDMI / DisplayPort
- BASE: 1019MHz / BOOST: 1071 MHz
- Reinforced backplate with side panel
- System power supply requirement: 600W
NEW WINDFORCE 3x 2 SLOT 450W cooling system
Keeping the same 450W Cooling capacity using only 2 slots, the New WINDFORCE 3x 450W cooling system is equipped with two 8mm and four 6mm cooper heat-pipes , inclined fans, and GIGABYTE "Triangle Cool" technology. This not only provides an effective heat dissipation capacity but GPU Boost 2.0 technology also enables higher performance due to a lower temperature.
OC GURU ll
Brand-new instinctive user interface, easier to monitoring and adjusting all important settings. Users can set up MONITORING, GPU CLOCK, MEMORY CLOCK, FAN, OSD, ONLINE SUPPORT and update driver, BIOS directly.
Up to 4 displays on a Single Card
Support up to four displays on a single card. Satisfy your multi-screen setup, high definition and extreme gaming experience.
8-Phase power Design
Compare to reference 6-phase power design, GV-N770OC-4GD V2.0 makes the MOSFET working at a lower temperature and provides more stable voltage output. Besides, over temperature protection and load balance to each MOSFET can effectively extend the card life.
Specifications:
- Chipset: GeForce GTX 780
- Memory Clock: 6008 MHz
- Core Clock: Base / Boost Clock: 1019 / 1071 MHz
- Process Technology: 28 nm
- Memory Size: 3072 MB
- Memory Bus: 384 bit
- Card Bus: PCI-E 3.0
- Memory Type: GDDR5
- Directx: 11.2
- OpenGL: 4.4
- PCB Form: ATX
- Digital max resolution: 4096 x 2160(via a single HDMI connector and not supported with two DVI connectors)
- Analog max resolution: 2048 x 1536
- Multi-view: 4
- I/O: Dual-link DVI-I x1 / DVI-D x1 / DisplayPort x1 / HDMI x1
- Card size: 292mm x 129mm x 43mm
- Power requirement: 600W (with two 8-pin external power connectors)
