NXP (LPC55S06-EVK) Development Board, MK64FN1M0VLL12, 32 Bit

Product InformationSilicon Manufacturer: NXPNo. of Bits: 32bitSilicon Family Name: LPCXpressoCore Architecture: ARMCore Sub-Architecture: Cortex-M33Silicon Core Number: MK64FN1M0VLL12Kit Contents: Development Board MK64FN1M0VLL12Product Range: -Product OverviewLPCXpresso55S06 development board provides the ideal platform for evaluation ofand development with the LPC550x/S0x MCU based on the Arm® Cortex®-M33architecture. The board includes a high-performance on-board debug probe andaccelerometer, with several options for adding off-the-shelf add-on boards fornetworking, sensors, displays, and other interfaces. LPCXpresso55S06 is fullysupported by the MCUXpresso suite of tools, which provides device drivers,middleware and examples to allow rapid development, plus configuration tools andan optional free IDE. MCUXpresso software is compatible with the open source MCUoperating system FreeRTOS, tools from popular tool vendors such as Arm and IAR,and the LPCXpresso55S06 may also be used with the popular debug probes availablefrom SEGGER and P&E Micro.MK64FN1M0VLL12 MCUI2C, UART and SPI port from LPC55S06CAN-FD transceiver and D-sub connector compatible with PCAN-USB FD adaptorOn-board, high-speed USB, Link2 debug probe with CMSIS-DAP and SEGGER J-Linkprotocol optionsHardware support for external debug probeNXP MMA8652FCR1 accelerometerMikroEletronika Click expansion optionLPCXpresso-V3 expansion connectors, compatible with Arduino® UNO R3PMod compatible expansion / host connectorRGB user LED, plus reset, ISP, Wake and user buttons
