Processor | Amlogic S805 SoC ARM® Cortex®-A5 (ARMv7) 1.5GHz Quad Core ARMv7 architecture @28nm wafer |
Memory | 1Gbyte DDR3 RAM 792Mhz |
3D Accelerator | ARM® Mali-450 MP2 OpenGL ES 2.0 / 1.1 |
Flash Storage | eMMC Module Socket : eMMC module (option) MicroSD Card Slot : 8 or 16GB MicroSD UHS-1 (option) |
USB2.0 Host | High speed standard A type connector x 4 ports |
USB2.0 Device/OTG | High Speed USB standard A type connector x 1 port |
Ethernet/LAN | 10/100/1000Mbps Ethernet with RJ-45 Jack (Auto-MDIX support) |
Video Output | Micro HDMI |
Audio Output | Micro HDMI |
Camera Input | USB 720p(option) |
Real Time Clock | On-board RTC function with a backup battery connector |
IO Expansion | 40pins |
WiFi | USB IEEE 802.11b/g/n 1T1R WLAN with Antenna (USB module) (option) |
Power | 5V 2A Power (option) |
System Software | Ubuntu 14.04 + OpenGL ES on Kernel 3.10 LTS Android 4.4.x on Kernel 3.10 LTS Full source code is accessible via our Github. |
PCB Size | 85 x 56 x 18 mm approx. (Weight : 40 gram) PCB Thickness : 1.0mm |
