General | |
---|---|
Brand | OLDSHARK |
Model | N/A |
Quantity | 1Piece |
Material | Plastic |
Form Color | Blue |
Specification | |
Screen Size | N/Acm |
Version | V2.1 |
Function | Read trouble codes , Check Engine Light (MIL) , Clear trouble codes , Display current sensor data , Caculate fuel oil consumption |
Readparam | Engine RPM , Intake Air Temperature , Air Flow Rate , Absolute Throttle Position , Oxygen sensor voltages associated short term fuel trims , Fuel System status , Fuel Pressure |
Wireless Bluetooth | Yes |
Transmit Distance | 10m |
Diagnose Interface | 16pin |
Supported Languages | English |
Smartphone Brand Supported | Samsung , LG , Sony Ericsson |
Application Supported | PC , Smartphone |
Software Platform Supported | Android , Symbian , PPC¿Windows Mobile) , Win XP |
Technical Parameters | |
Protocols Supported | ISO15765-4 (CAN) , ISO14230-4 (KWP2000) , ISO9141-2 |
Output Protocol | ISO15765-4 (CAN), ISO9141-2 |
Indicator LEDs | OBD transmit |
Baud Rate | 9600-38400bps |
Compatible Make | Universal |
Other Features | |
Working Voltage | 12V |
Working Current | 45mA |
Dimensions & Weight | |
---|---|
Dimensions | 1.81 in x 1.22 in x 0.98 in (4.6 cm x 3.1 cm x 2.5 cm) |
Weight | 0.74 oz (21 g) |
Packing List |
---|
1 x Scanner 1 x CD |
