O'Neil Datamax Termal Label Printer

Datamax E-Class MKIII Label Printer designed for a wide variety of applications.

The Datamax E-Class TM Mark III is a family of compact desktop thermal printers designed for a wide variety of industries and applications that require a reliable and cost-effective barcode printer. Datamax-ONeil by Honeywell applied its  expertise to provide an entry level printer that has the features and reliability normally found in more expensive printers. The E-Class Mark III is affordable to own, easy to use and economical to operate.

The Datamax E-Class Mark III is easy to use, with quick-loading media and an interactive LCD screen. Users can also notice a substantial reduction in their daily operational costs thanks to the E-Class Mark IIIs larger media and ribbon-roll capacity.
The Datamax E-Class Mark III is one of the best values on the market.

MECHANICAL
Dimensions
187 mm x 203.5 mm x 282 mm  (7.4 in x 8.01 in x 11.1 in)
Weight
2.4 kg (5.3 lbs)
Color
Pantone® warm gray
Construction:
Split case with rear concentric hinge; double-walled high-strength thermoplastic; clear wraparound media window

PRINT SPECIFICATIONS
Printer Type:
Direct thermal; optional thermal transfer
Print Length Range:
9.5 mm (0.375 in) to 2514 mm (99 in)
Color
Pantone® warm gray

MEDIA COMPATIBILITY
Media Type:
Label/Tag Roll
Width Range:
19 mm (0.8 in) to 112 mm (4.4 in)
Thickness Range:
0.06 mm (0.003 in) to 0.25 mm (0.01 in)
Winding:
Wound in or out
Ribbon:
Maximum outside diameter: 65 mm (2.6 in) Core diameters: 13 mm (0.5 in) or 25 mm (1 in) requires provided adaptors Minimum core widths: 109 mm (4.3 in) for 0.5 in diameter or 25 mm (1 in) for 1 in diameter M aximum core width: 109 mm (4.3 in) Width range: 25 mm (1 in) to 109 mm (4.3 in) Winding: coated-side-in or coated-side-out
Index Sensor Range:
Transmissive (top and bottom sensor combination): gap, hole or notch: Basic: 5 mm (0.2 in) right of CL A dv/Pro: 42 mm (1.7 in) left of CL to 34 mm (1.3 in) right of CL Reflective (bottom sensor only) bar, hole or notch: Basic: 5 mm (0.2 in) right of CL, A dv/Pro: 58 mm (2.3 in) left of CL to 34 mm (1.33 in) right of CL For optimum print quality and printer performance, use certified Honeywell media supplies
