Designed for scalable enterprise networks, the Open-Mesh S24 delivers robust cloud-managed performance with 24 high-speed Gigabit Ethernet ports and advanced Layer 2 switching features. This unit supports full PoE+ (802.3at) power across all ports and offers remote cloud configuration, ideal for centralised network deployments in office parks, schools, hospitality, and retail environments.
With support for advanced VLAN, STP/RSTP, link aggregation, port security, and SNMPv3, the S24 integrates easily into demanding LAN infrastructures. Cloud-based management and diagnostics help administrators monitor and optimise performance from anywhere.
Key Features & Benefits
24 x Gigabit Ethernet ports with full IEEE 802.3af/at PoE+ support
56 Gbps switching capacity with store-and-forward forwarding mode
Advanced Layer 2 features including VLAN groups, port trunking, 802.1X access control, and ACL
Full PoE management per-port power control, priority, and user-defined limits
Cloud-managed with CLI, SSH, Telnet, and SNMP v1/v2c/v3 support for flexible admin control
Cable diagnostics, Syslog, SNTP, and RMONv1 for enhanced fault tracking and uptime
Fanless design with internal PSU for quiet, efficient deployment
Ideal Uses
Powering VoIP phones, IP cameras, and wireless access points in small to mid-sized businesses
Centralised network control for hotels, schools, or multi-floor offices
Layer 2 secure networking in retail, education, or government institutions
Ideal backbone switch for unified network topologies requiring VLANs and IGMP snooping
Specifications
Condition: Refurbished device with minor scratches and scuffs. Device has been extensively tested and is fully functional.
Brand & Model: Open-Mesh S24
Ports: 24 x Gigabit Ethernet Ports with PoE+ (IEEE 802.3af/at)
Switching Capacity: 56 Gbps
Forwarding Mode: Store-and-forward
PoE Control: Power on/off per port, class configuration, priority, power limits
Mounting Options: Desktop, Wall Mount, Rack Mount (brackets included)
Memory: 256 MB SDRAM, 32 MB Flash
Management:
SSH / Telnet / CLI
Cloud Management Interface
SNMP v1/v2c/v3
BootP/DHCP, TFTP Client, SNTP
SYSLOG, RMONv1
Cable Diagnostics
Layer 2 Features:
Link Aggregation, Port Mirroring, Trunking
IGMP Snooping v1/v2/v3, MLD Snooping
Storm Control, Port Isolation, Voice VLAN
802.1X Port-Based Access Control & Guest VLAN
Spanning Tree Protocols: STP (802.1D), RSTP (802.1w), MSTP (802.1s)
Access Control Lists (ACL)
Attack Prevention
QoS Queues: Based on 802.1p, Physical Port, TOS, DSCP
LED Indicators: Power, Fault, PoE Max, LAN Mode, PoE Mode, Speed, Link/Act
MIB Support: RFC1213, RFC1493, RFC1757, RFC2674
Operating Temp: 0 to 50°C
Storage Temp: -40 to 70°C
Humidity: 5% 95% non-condensing
Dimensions: 43.9 x 31.0 x 4.3 cm
Weight: 5.74 kg
Warranty: 3 Month Carry-In Warranty
What's in the Box: Switch, Power Cable
