Maximum detection range 20m
Maximum arrival range 200m
Interruption period Selectable between 50, 100, 250, and 500m sec.
Power supply 10.5 - 28V DC
Current consumption (transmitter + receiver) 38mA (max.)
Alarm period 2 sec.(±1) nominal
Alarm output N.C. 28V DC 0.2A max
Tamper switch N.C. opens when cover is removed at 28V DC, 0.2A max.
Operating temperature -35°C to +60 °C Use the optional heating unit (HU-3) under the environment of -25°C or less minus.
Environmental humidity 95% max.
Alignment angle ±90° Horizontal, ±5° Vertical
Mounting Wall
Weight (transmitter+receiver)650g
Dimensions (H x W x D) 170mm x 65mm x 69.5mm
Weatherproof IP65
