Outdoor Gigabit Network RJ45 Surge Protector with 802.3AF PoE Support

Outdoor Gigabit Network RJ45 Surge Protector with 802.3AF PoE Support

It is suitable for the use of standard POE equipment and installation and protective forced power supply POE equipment, and supports the network power maintenance supply and surge protection. High-energy surge prevention components are used to protect the front and rear end devices from induced Input is the input end, Output is overvoltage, operating overvoltage and electrostatic discharge. The grounding cable and the grounding bus of the lightning protection system must be reliable.

Specifications:

• Model : SPD-POE1000E
• Nominal Voltage Un : (Data Signals) 5V , (Power) 48V
• Nominal Discharge Current (8/20s) I n : 1.5KA
• Maximum Flow Capacity (8/20s) I Max : 3KA
• PoE Limit Voltage Ur : 57V
• RJ45 Limit Voltage Ur : 15V
• Transmission Rate Vs : 1000Mbps
• Response Time Ta : 1ns
• Insertion Loss AE : 0.5dB
• Pin Protection : 1/2/3/6
• Connector Type : RJ45

Installation Video of RJ45 Surge Protection below

?v=invS-NoRYSY
