Outer CV joint for the Mitsubishi Outlander II (MK2) 2.4 MIVEC, with OE reference 3815A065. Supplied with grease and a nut, with 28 outer splines, 35 inner splines and a 160 mm length. Confirm compatibility by matching the listed fitment details and any OEM reference numbers supplied. Verify VIN/engine.
| Specification | Value |
|---|---|
| Outer Spline (wheel side) | 28 |
| Inner Spline | 35 |
| Outer Diameter | 90 mm |
| Seal Ring Diameter | 59.5 mm |
| Length | 160 mm |
| Thread Size | M22 x 1.5 |
| Groove Position | Inner |
| Supplied With | Grease and nut |
This outer CV joint is listed for 4 applications across the Mitsubishi Outlander II (CW_W), covering the 2.0 and 2.4 MIVEC petrol variants in front-wheel drive and 4WD, with supplied year coverage from 2006 to 2012. Use the full table below to confirm model, chassis / platform, year range, engine and power before ordering.
| Model | Chassis | Years | Engine | Power |
|---|---|---|---|---|
| Outlander II | CW4W | 11/2006-11/2012 | 2.0 MIVEC (4B11) | 108 kW |
| Outlander II 4WD | CW4W | 11/2006-11/2012 | 2.0 MIVEC (4B11) | 108 kW |
| Outlander II | CW5W | 11/2006-11/2012 | 2.4 MIVEC (4B12) | 125 kW |
| Outlander II 4WD | CW5W | 09/2007-11/2012 | 2.4 MIVEC (4B12) | 125 kW |
Important: With CV joints and driveshafts, a VIN check can still return multiple possible variants within the same model range. First confirm whether you need an inner CV joint, outer CV joint, CV boot, or complete driveshaft. Then match the removed unit by outer spline count, inner spline count, seal size (mm), outer diameter (mm), groove position, overall length (mm), and ABS ring tooth count where applicable. The only reliable way to confirm the correct part is to physically inspect and measure the old unit and match these specifications before ordering.
Returns Notice: CV joints, driveshafts, and boots that are greasy or incomplete are not returnable.
Will this outer CV joint fit my Mitsubishi Outlander?
This part (MI3015) is listed for the fitments shown on this page. Confirm by matching the fitment details. Verify VIN/engine.
What OEM part numbers does this cross-reference?
Cross-reference numbers are listed in the Key Details section above. Match at least one to your original part before ordering.
What is included?
CV joint, grease and nut.
How do I confirm fitment if there are multiple variants?
Compare the supplied fitment details, OE reference numbers, original part details and any listed variant information before ordering. Verify VIN/engine.
