Panasonic (ASQ10230) Microswitch, Turquoise Stroke, Snap Action

Product Information:Microswitch Type: Snap ActionMicroswitch Actuator: Pin PlungerContact Configuration: SPST-NOSwitch Terminals: Wire LeadedContact Current Max: 100mAContact Voltage DC Nom: 30VDCProduct Range: ASQ1Contact Voltage AC Nom: -Operating Force Max: 1.5NProduct Overview:The ASQ1 series-long stroke and sliding contact construction Sealed Switchfeatures since contact force does not depend on the operation stroke, the rangeof possible use over the entire stroke is greatly increased. For pin plungertype, it maintains a long stroke OT (over travel) with over 2.2mm on the NO sideand over 2.5mm on the NC side.High contact reliability to support low-level switching loadsHighly effective sealing for resistance against adverse environmentsSilent operation with sliding contactWire-lead, solder and PC board terminals are availableSPDT, SPST-NC and SPST-NO contact formIP67 Protection rating (except exposed terminal part of terminal type)Applications:Automotive, Consumer Electronics, HVAC
