Panasonic (EEUFR1C471B) Electrolytic Capacitor, 470 µF, 16 V

Electrolytic Capacitor, 470 µF, 16 V, ± 20%, Radial Leaded, 6000 hours @ 105°C,PolarProduct InformationCapacitance: 470µFVoltage Rating: 16VVoltage(DC): 16VCapacitance Tolerance: ± 20%Capacitor Terminals: Radial LeadedLifetime @ Temperature: 6000 hours @ 105°CPolarity: PolarDiameter: 8mmSeries Name: FRLead Spacing: 5mmHeight: 11.5mmProduct Diameter: 8mmOperating Temperature Min: -40°COperating Temperature Max: 105°CProduct Height: 11.5mmESR: -Lead Diameter: 0.6mmProduct Length: -Qualification: -Supplier Package: -Product Range: FRAutomotive Qualification Standard: -Product OverviewThe Panasonic FR series capacitors are type A, radial leaded polarized aluminiumelectrolytic capacitors. The capacitance value ranges from 4.7µF to 8200µF.These capacitors are perfect solution for applications, which require ultra lowESR, very high ripple current and very long life in small mounting form. Incomparison to Panasonic FM series, the FR series capacitors can achieve aendurance upgrade of up to 100% and a capacitance increase of up to 30% byimproving material technology.Rated voltage range of 6.3VDC to 100VDCTolerance of ±20%Endurance of 5000h to 10000h at 105°COperating temperature range -40°C to 105°CHigh reliability
