If youre searching for a cost-effective POS terminal that doesnt compromise performance, look no further.
In high-traffic, high-impact environments, durable POS hardware is essential. Rugged POS hardware decreases
long-term total cost of ownership and increases the return on investment of your hardware. An attractive,
die-cast aluminum housing protects the SP-850 rated IP54 from damage from dust, dirt and spills. In
addition, its fanless design minimizes damage to internal components caused by dust.
Flexible Format for Any Job
Versatility and flexibility are traits you look for and encourage in your staff. Why would you settle for POS
hardware thats any different? No matter the POS functionality you require, the SP-850 can handle it. Partner
Tech offers a wide variety of peripherals that are easily connected to the terminal, including RFID reader,
chip card reader, MSR, biometric reader, and secondary display options for maximum customer engagement
SPECIAL FEATURES
Elegant and robust aluminum die-cast housing
Powerful Intel® Bay Trail quad core processor J1900
Supports up to 8GB RAM
Flexible modular design and customer display / 2nd
monitor support
Spill and dust resistant front panel, IP65
(Whole device IP54 certified)
Convenient VESA / wall mount and wide tilt angle
monitor
Spec
Intel® Celeron J1900 (2.00GHz up to 2.42GHz), quad core, 2MB L2 Cache, fanless
Bezelfree 15 TFT-LCD, resolution 1024 x 768, brightness 350cd/m², LED backlight
Projected Capacitive Touch (Multi Touch) with USB interface
DDR3L SO-DIMM, 2 slots up to 8GB
1 x 2.5 SATA HDD or SSD (option)
1 x RJ-45 10/100/1000 BASE-T Gigabit Ethernet
4 x COM (DC+0/5/12V: COM 1-2 BIOS selection, COM 3-4 by jumper)
5 x USB 2.0
1 x USB 3.0
1 x PS/2
1 x RJ-45 Ethernet
1 x RJ-11 Cash drawer control (for 2 cash drawers)
1 x VGA
1 x DC + 12V Out
1 x Mini PCI-e (internal)
1 x 3W speaker (internal)
Windows 7, POSReady 7, Windows 8.1, Windows 10, Linux (ubuntu)
AC100~240V/DC+12V, 7.5A, 90W power adaptor
14.17in (W) x 9.17in (D) x 12.71in (H)
Operating: Storage:
Temperature: 32F ~ 104F -4F ~ 140F
Humidity: 15% ~ 80% 15% ~ 80%
3-track MSR, customer display (2x20 VFD, CD-70), 2nd monitor (PM-116, PM-15BZ PCT)
SSD, IC card reader, NFC/RFID reader, i-Button/Dallas/Addimat
black
