PAWTEK HDMI Extender Transmitter + Receiver Kit (Up to 60M) Over Single Cat5e/6 Bidirectional IR

IN STOCK at GeeWiz!
If ordered before 4PM:
DELIVERED next business day (main centres)
or 3-5 days (regional areas or large items)
COLLECTION from GeeWiz available SAME DAY
Also available for in-store purchase during business hours!

NOTE: Item to be used with high quality solid copper cable only and does not come with IR Sensors.

PRODUCT DESCRIPTION

The HDMI Extender over Single Cat5e/6 with Bi-directional IR extends high definition video and audio signals and IR, at a distance of up to200ft/60m over a single Cat5e/6 cable.Also, it can distribute a HDMI signal to local HDMI output port.Features EDID management, which allows and encourages source and display "handshake" for seamless integration. With only one cost effective Cat5e/6 cable, high definition sources with HDMI outputs can be connected to high definition displays with HDMI inputs over long distances. Deep color video, DTS-HD or Dolby TrueHD audio is supported and compatible with the extender. In addition, the extender is also equipped with bi-directional IR pass-through which allows for source or display control.
The extender includes two units: transmitting unit and receiving unit. The transmitting unit is used to capture the HDMI input with IR signals and carries the signals via one cost effective Cat5e/6 cable. The receiving unit is responsible for equalizing the transmitted HDMI signal and reconstructing IR and serial control signals. The extender offers the most convenient solution for HDMI extension over a single Cat5e/6 with long distance capability, and is the perfect solution for any application.

• Transmits HDMI video and audio signals up to 60M over a single CAT6 cable
• Support video resolution up to 1920x1080p@60Hz
• SupportEDID copy function
• Support bidirectional 20-60KHz IR
• Support POE Power function, power adapter only connects to either TX or RX
• Transmitter support one channel local output
• Compliance with HDMI 1.3 and HDCP 1.2 standard
• Built-in aoutomatic adjustment system, makes the image smooth, clear and stable
• Built-in ESD protection system
• Easy installation, plug and play

PRODUCT SPECIFICATIONS
