PC Power Supply Tester - For new and older type connectors

The power supply tester is a robust voltage, tester for PC-power supply. ATX, BTX and ITX compliant, power supply can be tested, indicate the status of voltage. The PC/SPS is suitable for the ambitious hobby user, as well as for a quick functional check in specialized trade.

• Tests both new power supplies and older ones with -5V circuits
• Tests: 20 and 24 pin atx connector, molex, floppy, sata, P4, 6 pin PCI Express, and 8 pin CPU

The methods of operation

A. Plug power supply 24PIN and P4, P6 or P8 into the corresponding jack of the power test suit.
B. Power on the supply of power, will hear DuDu ring, if no flicker then the power supply output voltage is normal.
C. If a certain voltage signal is not detected, or the detected voltage value over the normal, will issue a DuDu long buzzer; if the corresponding voltage value or PG flicker too, then the power is failed.

• Compatible with ATX12V 1.0, 1.1, 1.2, 1.3, 2.0, 2.01, 2.1, 2.2, 2.3
• 3.5 inches long x 2.5 inches wide x 3/4 inches thick
• ATX connector input (20/24 pin)
• P4 input
• 8 pin CPU input
• Molex, sata, and floppy inputs
• 6 pin PCI Express input
