PCIE 4 RJ45 PORT LAN CARD - TXA034

Gigabit Dual Network Port Network Card

Model Number: TXA020

Chipset: Intel 82575 Gigabit Controller

Port Number 2 x RJ45

Standard: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x

Data Rate: 10/100/1000Mbps. Interface: PCI express 4x

LED Indicator: 8 LED 10/100/1000Mbps(Link/Act)

Dimension: 105.5 x 68.6 x17.5mm

Support OS:

Microsoft Windows Server 2003, Enterprise, Datacenter (32- and 64-bit)

Microsoft Windows 2000

Red Hat Linux 2.4x or later (32- and 64-bit)

FreeBSD 4.x or later

Novell Netware 5.x, 6.x

Sun Solaris x86, OS 8 and later

SCO Open Server 5, Open UNIX 8

Environment:

Operating Temperature: 0 ?-55 ?

Relative Humidity: 10%-90%(non-condensing)

Storage Temperature: -0?-80?

Relative Humidity: 5%-90%(non-condensing)

Other Features:

Load balancing on multiple CPUs

Interrupt moderation

Compatible with x4, x8, and x16 full-height PCI Express slots

Support for most Network Operating Systems (NOS)

Remote Management Support

Category-5 unshielded twisted pair (UTP), 4-pair Cabling

RoHS compliant, lead-free Technology

Intel PRO Set Utility for Microsoft Device Manager

Advanced cable diagnostics

Intel backing

Features:

Uses x4 PCI Express interface on MCH device

Peak bandwidth 2 GB/s in each direction per PCI Express lane

PCI Express Power Management

High bandwidth density per pin

IEEE 802.3x compliant flow control support with software controllable pause times and threshold values

Support for transmission and reception of packets up to 9.5 kB

IEEE 802.3x compliant flow control support with software controllable pause times and threshold values

Operates with worst-case cable

Supports carrier extension and packet bursting (half duplex)

Advanced Power Management - ￂﾕ Low power link up ￂﾕ Smart Power Down - Link disconnect

Support for limited auto MDIO register init - limited number of registers

SERDES Signal Detect and support of non-AN partner

Auto crossover for MDI

Smart Power Down

Transmit and receive IP, TCP and UDP checksum off-loading capabilities

IEEE 802.1q VLAN support with VLAN tag insertion, stripping and packet filtering for up to 4096 VLAN tags

Double Vlan
