Pentax AF-500FTZ

This flash was designed for PENTAX film autofocus cameras and is quite powerful with a guide number of 50 (ISO 100 in meters with a 85mm lens). The flash has a zooming flash head, which tilts and swivels for bounce flash.

On non-autofocus cameras and on DSLRs without TTL support (PENTAX K-series DSLRs, *istDL/DL2) the flash can only be used in manual flash mode.

Optional accessories:
TR PowerPack 2

Flash name	Guide Number (meters ISO 100)	Flash control	Flash exposure comp.	Flash range
PENTAX AF 500FTZ	42 in 50mm zoom setting, 50 in 85mm zoom setting	TTL auto Manual (6 power settings)	No	TTL auto: 0.7 - 30m at 50mm zoom position with f/1.4 lens at ISO 100
Flash coverage (24x36)	Flash coverage (APS-C)	Rotating flash head	Modeling light	Autofocus spotbeam
24mm lens	16mm lens	Yes, tilt and swivel	No	Yes
Sensor angle	Connections	Hot shoe pins	Batteries	Recycle time
No sensor	Hot shoe, 5P cable, external power	5 (incl. ground)	4 x AA	9s, 4s with Power pack TR2
Dimensions (W x H x D)	Weight	In production
