Phoenix Contact (1727036) Wire-To-Board Terminal Block, 3.81 mm, 4 Ways

Wire-To-Board Terminal Block, 3.81 mm, 4 Ways, 26 AWG, 16 AWG, 1.5 mm², ScrewProduct OverviewThe 1727036 is a 4-position green PCB Terminal Block with tin-plated soldercontacts, a polyamide insulator and the M2 screw connection. This MKDS 1/ 4-3,81terminal block has fully developed contact geometries and surfaces. It accepts26 to 16AWG wire range.Space-saving and safeSingle-row type with horizontal connection direction5mm Stripping lengthUL94V-0 Flammability ratingApplicationsIndustrialProduct InformationPitch Spacing: 3.81mmWire Size AWG Min: 26AWGWire Size AWG Max: 16AWGConductor Area CSA: 1.5mm²Wire Connection Method: ScrewRated Current: 10ARated Voltage: 300VBlock Orientation: Through Hole Right AngleProduct Range: MKDS
