Phoenix Contact (1803646) Pluggable Terminal Block, 3.81 mm, 9 Ways

Pluggable Terminal Block, 3.81 mm, 9 Ways, 28AWG to 16AWG, 1.5 mm², Screw, 8 AProduct OverviewThe 1803646 is a 9-position green pluggable PCB Terminal Block with tin-platedsolder contacts, a polyamide insulator and the M2 screw connection. This MC 1,5/9-ST-3,81 terminal block has fully developed contact geometries and surfaces. Itaccepts 28 to 16AWG wire range.Generously dimensioned wiring spacePlug-in direction parallel to the conductor axisLow design height of the MC 1,5 plug range7mm Stripping lengthA1 Internal cylindrical gageUL94V-0 Flammability ratingApplicationsIndustrialProduct InformationPitch Spacing: 3.81mmNo. of Positions: 9WaysWire Size (AWG): 28AWG to 16AWGWire Size AWG Min: 28AWGWire Size AWG Max: 16AWGConductor Area CSA: 1.5mm²Wire Connection Method: ScrewRated Current: 8ARated Voltage: 160VProduct Range: MC
