Phoenix Contact (DMC 1,5/ 4-G1F-3,5-LR P20THR) Terminal Block, Header

Terminal Block, Header, 3.5 mm, 8 Ways, 8 A, 160 V, Through Hole Right AngleProduct OverviewThe DMC 1,5/ 4-G1F-3,5-LR P20THR is a 4-position 8A black Terminal Block Headerwith THR mounting designed for integration into the SMT soldering process. The1787030 has tin contact surface with LCP insulator. The headers with flange canbe combined with plugs with screw flange or with lock and release levers, At 8mmthe distance from the edge of the PCB to the first row of holes is compatiblewith MC headers.UL94V-0 Flammability ratingExtremely small THR double-level headers for SMT and wave soldering processesScrewable flange for superior mechanical stabilityAutomatic locking & intuitive release through Lock & Release operating lever incontrasting colourConductor connection on several levels enables higher contact densitySmall component size for applications where space is at a premiumApplicationsIndustrialProduct InformationPitch Spacing: 3.5mmNo. of Positions: 8WaysRated Current: 8ARated Voltage: 160VBlock Orientation: Through Hole Right AngleProduct Range: DMC
