Phoenix Contact (MC 1,5/12-G-3,5) Terminal Block, Header, 3.5 mm

Terminal Block, Header, 3.5 mm, 12 Ways, 8 A, 300 V, Through Hole Right AngleProduct OverviewThe MC 1,5/12-G-3,5 from Phoenix Contact is a 3.5mm pitch, 12 pole header. Theheader has a plug-in direction parallel to the PCB.Nominal current is 8ARated voltage (III/3) is 160V, (III/2) is 160V, (II/2) is 250VRated surge voltage (III/3) is 2.5KV, (III/2) is 2.5KV, (II/2) is 2.5KVGreen colour PBT insulating material, flammability rating according to UL94 V0Maximum flexibility designContact surface is tinCSA, VDE, CCA, cULus, EAC standardsHole diameter is 1.2mmPin dimension is 0.8mm x 0.8mmApplicationsIndustrialProduct InformationPitch Spacing: 3.5mmNo. of Positions: 12WaysRated Current: 8ARated Voltage: 300VBlock Orientation: Through Hole Right AngleProduct Range: MINI COMBICON
