Phoenix Contact (MSTB 2,5/ 2-GF-5,08) Terminal Block, Header, 5.08 mm

Terminal Block, Header, 5.08 mm, 2 Ways, 12 A, 320 V, Through Hole Right AngleProduct OverviewThe MSTB 2,5/ 2-GF-5,08 from Phoenix Contact is a 5.08mm pitch, COMBICON PCBbasestrip with 2 position. The plug-in direction parallel to the PCB andconnection in accordance with EN-VDE standard.Nominal current is 12ARated voltage (III/3) is 250V, (III/2) is 320V, (II/2) is 400VGreen colour polyamide insulating materialFlammability rating according to UL 94 V0Maximum flexibility designHole diameter is 1.4mmContract surface is tinApplicationsIndustrialProduct InformationPitch Spacing: 5.08mmRated Current: 12ARated Voltage: 320VBlock Orientation: Through Hole Right AngleProduct Range: MSTB
