Description:

The Axiomtek PICO880 is a Pico-ITX single-board computer (SBC) designed for embedded systems. It utilises a 5th-generation Intel Core i5 processor (Broadwell). Key features include support for up to 8GB of DDR3L memory, a full-size PCI Express Mini Card slot with mSATA support, and various I/O options like DisplayPort, LVDS, Gigabit Ethernet, and USB. The PICO880 is aimed at applications like vehicle PCs, industrial automation, and medical imaging.
Detailed Features:
Processor: 4th and 5th generation Intel Core i5 processor (Haswell/Broadwell).
Memory: 1 DDR3L SO-DIMM slot, supporting up to 8GB of memory.
Expansion: One full-size PCI Express Mini Card slot with mSATA support.
Display: DisplayPort and 18/24-bit single/dual-channel LVDS interfaces.
Networking: Gigabit Ethernet with Wake-on-LAN and PXE support.
Storage: SATA 6Gb/s interface.
USB: 1 USB 2.0 port.
Other I/O: Optional expansion boards for additional RS-232/422/485, USB 3.0, HDMI, and VGA ports.
Operating Systems: Supports Windows 7 and 8.1.
Remote Management: Supports Intel AMT 9.5 and Intel vPro Technology.
Form Factor: Pico-ITX (100mm x 72mm).
Operating Temperature: Supports a wide temperature range, typically from -20°C to +70°C.
Applications: Vehicle PCs, small media entertainment systems, industrial automation, medical imaging, and gaming.
