PLC Mitsubishi FX2N-128MR 100-240Vac
The most advanced series in the FX family of PLC’s. It is compact, offers extremely fast program execution, accepts up to eight special function modules and provides maximum flexibility and control power for all your factory automation applications. In addition to the features already listed, the FX2N also offers the following:
High processing speed, 0.08μs/basic instruction
125 applied instructions, 3072 auxiliary relays, 256 timers, 235 counters, 8000 data registers
8K step RAM program memory (expandable to 16K with EEPROM)
24Vdc 460mA output for sensors etc (250mA for 16 and 32 I/O)
All have 24Vdc inputs which can be configured as sink or source
27 basic instructions
60kHz high speed counter
DIN rail or surface mount
Password security
Real time clock and Run/Stop switch built in
Relay outputs rated 240Vac or 30Vdc, up to 2A per point max.
Transistor outputs rated 5V to 30Vdc, up to 0.5A per point max.
Program using GX developer FX software
Ac powered supply voltage 100-240Vac +10% -15%, 50/60Hz
0.55 to 0.7μs/basic instruction processing
Two potentiometers built in for adjusting timers etc
