Power Works Artemis 10PD Active PA Speaker with DSP - Each - Black
The ARTEMIS Series of Active Plywood enclosure have been designed as a high performance, light weight Audio Solution.
There are 4 models in the range 8, 10, 12 and 15. The speaker box can also be used as a stage monitor.
Equipped with High Power Woofers and compression drivers. The speakers deliver high definition audio with a wide frequency response.
Bi-Amped Active Speaker
350W RMS 700W Peak Power
Amplifier Class-D (low-frequencies); Class-AB (high-frequencies)
Graphic back-lit display DSP Display
Sturdy and Lightweight Polypropylene Enclosure with black anti-scratch paint
Standard D35mm tripod / pole hole
30° and 45° Stage Monitor Usable Angles
Clear Sound for Mobile and Installed Systems
2-Way Active Sound-Reinforcement Loudspeakers
10" 700W Peak 2-way Powered Loudspeakers with Ease of use DSP
ARTEMIS Series speakers are part of a full range of PowerWorks Pro Audio product line up. Compact and lightweight, active loudspeakers provide a rich, extended low-end and natural high-frequency in a Plywood enclosure that is easily transportable.
Two Integrated Amplifiers
Backed by 600W (dynamic) of Class D/Class AB power and enhanced with easy-of-use DSP tuning functions, the ARTEMIS Series gives you all the power and DSP you need for both mobile and installed sound applications. Class D and Class A/B amplifiers are utilised to provide optimal response throughout the speaker's frequency range. A 250W (continuous), Class D amplifier powers the 10-inch low-frequency driver, providing efficient, clean power for low end when you need it. A 50W (continuous), Class A/B amplifier powers the 1.35-inch high-frequency driver, delivering a natural sounding high end. The combination can deliver up to 120 dB SPL (max) of clear sound between 65 Hz and 19 kHz. Specially selected transducers and compression drivers with a powerful DSP, advanced housing material and anti-scratch black paint: all Components combined to offer the best quality and value for the most demanding Audio professionals. PowerWorks ARTEMIS series of 8, 10, 12" and 15" woofers are punchy and loud.
There is a 1.35" compression driver in the 8, 10 and 12 versions and a 1,75 compression driver in the 15 version with both compression drivers delivering crystal clear sound. There are three inputs with selectable inputs of Line/Mic with separate level controls on 2 inputs.
Flexible inputs.
ARTEMIS Series of full-range loudspeakers offer a choice of inputs so you can use them with a variety of sources. You get two combo XLR mic/Jack line inputs, each with a microphone/line level preamplifier and independent gain control. A stereo 3,5mm Jack connection signal input for use with smartphones, tablets, and other consumer audio devices. These signals can be combined with the internal mixer, and a balanced XLR Mix output lets you send the signals to other ARTEMIS-series loudspeakers or an Active Sub-Woofer.
An Incredible Audio solution.
With the power-amp configuration, carefully programmed DSP presets, versatile mounting options, flexible inputs with onboard mixing, and other professional features, ARTEMIS-series loudspeakers are an excellent choice for both mobile and installed sound applications. Easy transportability and extremely affordability.
Specifications:
Frequency Response 65Hz 19kHz / -10dB
Max SPL 120 dB
Low-freq. Transducer 10 Woofer 2 Voice Coil
High-freq. Transducer 1.35 Compression Driver
Coverage H90° x V60°
Crossover Frequency 3,2kHz
Low-Frequency Amplifier Class-D 300W RMS 600W Peak
High-Frequency Amplifier Class-AB 50W RMS 100W Peak
Power Consumption 350W
Fuse T3.15A-250V
AC Mains 220/240V 50/60Hz
Input Connections 2 x COMBO (XLR + 1/4 Jack, balanced)+3,5mm Jack
Output Connections 1 x XLR (Mix output, balanced)
Housing material Plywood Cabinet
1.2mm Steel Grille
Handles 2 on sides
Tripod/Pole Hole Duo-tilt 0° and 7°
Stage Monitor Use Angle 30° and 45°
Speaker Size (WxHxD) 380 x 570 x 400 mm
Packing Size (WxHxD) 390 x 580 x 410 mm
Speaker Weight 17.4 kg
Carton Weight 18.4 kg
