Pure Sine Wave Inverter Charger
The 5.5kW pure sine wave hybrid inverter is capable of bidirectional current conversion (DC to AC/ AC to DC) while regulating the output voltage to 230Vac 5% or 48Vdc with no damage to electrical equipment. This feature makes it ideal for powering most household appliances.
Integrated Mppt Charge Controller for Multiple Battery Types
The Built-In MPPT controller is versatile in charging both 48V lead-acid batteries (Flooded, AGM,SLA, Gel), LiFePO4 and lithium batteries ( User Mode), utilizing energy from solar panels, the grid, or a generator. With a maximum PV Array Power of 5500W and a PV input voltage range of 120-450V DC, this controller offers flexibility in various power input options.
Four Safe Charging Modes & Two Output Modes
The inverter offers 4 charging and 2 output modes, giving users power input and output customization options. The power-saving mode reduces empty load loss, and it can be switched on to reduce no-load consumption.
Intelligently All-Round Protection
PowMr inverter charger operates in 4 charging stages, provides protection against Overload, Over temperature, and Short circuit, and has automatic restart capability. Intelligent variable speed fans enhance battery performance, dissipate heat, and prolong system lifespan.
PDF Manual Download
Specifications (See PDF Manual for full list of specifications)
| Model | POW-HVM5.5K-48V-N |
| Brand | PowMr |
| Rated Load Power | 5.5kW |
| AC Output | 230Vac5% |
| DC Battery Output | 48Volt |
| Phase | Single Phase |
| PV Array MPPT Voltage Range | 120-450V (Max. PV Array Open Circuit Voltage: 500V) |
| Max Solar Panel Input Power | 5500 Watt |
| Compatible Battery | LiFePO4 Batteries, AGM Batteries, Lithium Batteries, Flooded Batteries, User Mode, Sealed Lead Acid Batteries, Gel Batteries |
| Parallel Capability | No |
| Warranty | 2 Years |
This product must be installed by a qualified electrician/technician. All installations must adhere to local wiring regulations and standards. Zaptor Distribution will not be held liable for any product malfunctions as a result of incorrectly installed systems.
