PowMr BE24 Battery Balancer for 24V & higher

The Battery Equalizer is used for the 12V Gel/Flood/AGM Lead Acid Batteries which are connected in series to keep battery voltage balance. When two or more series-connected batteries are in charging/discharging/free status. The battery voltages maybe become different. One battery voltage is high and one is low. The battery equalizer will equalize/balance the battery voltage when it detects there is 20mV between two batteries. It will shunt current from one battery (the higher voltage one) to the other battery (the lower voltage one). Until their battery voltage almost becomes the same. This will improve the battery's performance and extend the battery's lifetime.

A battery equalizer can be used for 24V, 36V, 48V, and any other N*12V battery system.

• 1 pieces for 24V system;
• 2 pieces for 36V system;
• 3 pieces for 48V system; etc.

Packaging & Delivery

• Selling Units: Single item
• Single package size: 13.6x11.9x5.3 cm
• Single gross weight: 0.3 kg

Connection:

1. Black wire connects the negative pole of the series battery pack
2. Red line connects the positive pole of the series battery pack
3. The white line connects the intermediate connection points of the two batteries.

Please read the specification carefully before install

Specification
